Metco 1001A is an iron-based hardfacing material specifically designed to provide extreme wear and impact resistance for bulk-welded wear plate applications in conjunction with a solid iron wire. It provides the best performance in aggressive environments where impact and abrasive wear are critical sources of failure. Metco 1001A deposits can have wear resistance that is up to 4 times that of chromium carbide overlays, and significantly better service life compared to tungsten carbide overlays.
Characteristics
| Material type | Welding/Cladding Powder |
|---|---|
| Product form | Powder |
| Material safety datasheet number | 50-2305 |
| Achieved surface function primary |
Abrasion Protection Impact Resistance |
| Suitable for service environmen |
Gravel/Stone/Rock/Concrete Contact Soil//Sand/Silt/Clay Contact Moderate Atmosphere |
| Base composition | Iron |
| Nominal chemistry | Proprietary |
| Achieved microhardness (min) | 65HRC |
| Achieved macrohardness (max) | 69HRC |
| Hard phase portion | 40% |
| Recommended process technology |
Submerged Arc Bulk Powder Welding |
| Datasheet number | DSM-0215 |
