Metco 1030B

Metco 1030B

Metco 1030B is a cost-effective, martensitic alloy with fine molybdenum borides and vanadium carbides. It has excellent performance in aggressive environments where impact and abrasive wear are critical sources of failure. The chromium-free composition enables a safer processing environment. Impact performance can be as much as 20-times that of WC-Ni and more than 4-times better than chromium carbide overlays or nanostructured forming steels. It has a finer size distribution than Metco 1030A.

Characteristics

Material type Welding/Cladding Powder
Product form Powder
Material safety datasheet number 50-2023
Previous name Vecalloy 600
Achieved surface function primary Abrasion Protection
Erosion Protection in Gas Flow
Erosion Protection in Liquid Flow
Impact Resistance
Solid Particle Erosion Protection
Dimensional Restoration
Suitable for service environmen Dust
Base composition Iron
Nominal chemistry Proprietary
Achieved microhardness (min) 66HRC
Achieved macrohardness (max) 68HRC
Hard phase portion 33%
Recommended process technology High-Speed Laser Cladding
Datasheet number DSM-0206

Relevant articles

Article Number Product Size Packaging size
1300146 Metco 1030B -53 +20 μm 10.0 lb Inquire / Contact Us
