Metco 1040A is a manganese steel compatible hardfacing overlay with an austenitic matrix and a high carbide fraction for wear and extreme abrasion resistance. In many mining processes where manganese steel is used, gouging or wear occurs before the steel has a chance to work harden. It is designed to be applied using laser cladding or Plasma Transferred Arc. Overlays of Metco 1040A work harden quickly in service to ≥ 63 HRC.
Characteristics
| Material type | Welding/Cladding Powder |
|---|---|
| Product form | Powder |
| Material safety datasheet number | 50-2211 |
| Previous name | Vecalloy 800 |
| Achieved surface function primary |
Abrasion Protection Erosion Protection in Gas Flow Erosion Protection in Liquid Flow Impact Resistance Solid Particle Erosion Protection |
| Suitable for service environmen |
Gravel/Stone/Rock/Concrete Contact Soil//Sand/Silt/Clay Contact |
| Base composition | Iron |
| Nominal chemistry | Proprietary |
| Achieved microhardness (min) | 46HRC |
| Achieved macrohardness (max) | 47HRC |
| Recommended process technology |
Laser Cladding Plasma Transferred Arc |
| Datasheet number | DSM-0208 |
