- Choose Metco 8233 to produce weld overlays for service conditions where both abrasion and impact resistance are a concern - When welded on a non-magnetic substrate, the Metco 8233 overlay will also be non-magnetic - Metco 8233 work hardens in service providing improved impact resistance while retaining very good abrasion resistance - Metco 8233 is compatible with manganese steels
Characteristics
| Material type | Wire Material |
|---|---|
| Product form | Wire |
| Material safety datasheet number | 50-2329 |
| Achieved surface function primary |
Impact Resistance Abrasion Protection |
| Achieved surface function secondary |
Cavitation Protection Other |
| Suitable for service environment |
Soil//Sand/Silt/Clay Contact Slag Melt Dust |
| Melting temperature | 1200 |
| Base composition | Iron Based |
| Nominal chemistry | FeCrMnC |
| Achieved microhardness (min) | 50HRC |
| Achieved macrohardness (max) | 56HRC |
| Achieved weld density | 7.65 |
| Datasheet number | DSM-0207 |
