Metco 8247 is an iron-based composite wire with titanium carbide hardphase designed for application using GMAW. It creates crack-free deposits that are more abrasion resistant than competitor products and highly impact resistant. Deposits apply cleanly with little spatter, thereby reducing post-deposit machining requirements. Use Metco 8247 for hard banding, ground engaging tools in mining and agriculture, as well as oil and gas downhole tools.
Characteristics
| Material type | Wire Material |
|---|---|
| Product form | Wire |
| Material safety datasheet number | 50-2468 |
| Previous name | Metco X9 |
| Achieved surface function primary |
Abrasion Protection Solid Particle Erosion Protection |
| Achieved surface function secondary |
Impact Resistance |
| Suitable for service environmen |
Gravel/Stone/Rock/Concrete Contact Soil//Sand/Silt/Clay Contact |
| Melting temp. | 1500 |
| Base composition | Iron |
| Nominal chemistry | Proprietary |
| Color | Grey |
| Max. service temp. | 700 |
| Achieved microhardness | 710% |
| Achieved microhardness (min) | 58HRC |
| Achieved macrohardness (max) | 60HRC |
| Hard phase portion | 10% |
| Achieved weld density | 8.0 |
| Recommended process technology |
Gas Metal Arc Welding Submerged Arc Welding |
| Recommended finishing | Grinding Only |
| Datasheet number | DSM-0211 |
