Metco™ 8526 is a silver-based alloy that has a higher melting temperature and higher strength than pure silver. As a braze filler metal, Metco 8526 can be used to join copper, brass, nickel-silver, bronze, steel, and other non-ferrous alloys that melt above 765 °C (1450 °F). It can join dissimilar metals like ferrous to non-ferrous substrates, such as nickel, copper, brass and silver, with close joint clearances. Its wide melting range of 90 °C (160 °F) can be used in wide-gap applications.
Characteristics
| Material type | Wire Material |
|---|---|
| Product form | Wire |
| Material safety datasheet number | 50-862 |
| Predesessor material |
Silvaloy |
| Previous name | Metco Silverloy |
| Achieved surface function primary |
Dimensional Restoration |
| Suitable for service environmen |
Combustion/Flue Gas |
| Melting temp. | 677 |
| Liquidus temp. | 677 |
| Solidus temp. | 766 |
| Base composition | Silver |
| Nominal chemistry | Ag 38Cu 32Zn |
| Achieved microhardness | 25 |
| Achieved microhardness (min) | 25HRB |
| Customer specification approved |
AWS A8.5/A5.8M BAg-20 Rolls-Royce plc MSRR 9507/113 |
| Recomm metco spray gun |
16E |
| Recommended process technology |
Brazing |
| Datasheet number | DSM-0200 |
