WokaDur NiE-Tube is a pure nickel tubular wire with cast tungsten carbide (CTC) designed to be applied via GMAW. Deposits are extremely resistant to abrasive and erosive particles, while remaining very ductile. Deposits are crack-free with very uniform carbide distribution that exhibit outstanding wear resistance WokaDur NiE-Tube is compatible with mild and low carbon steel substrates with a carbon content ≤ 05%.
Characteristics
| Material type | Wire Material |
|---|---|
| Product form | Wire |
| Material safety datasheet number | 50-1085 |
| Achieved surface function primary |
Abrasion Protection Erosion Protection in Liquid Flow Solid Particle Erosion Protection |
| Suitable for service environmen |
Moderate Atmosphere Dust Gravel/Stone/Rock/Concrete Contact Soil//Sand/Silt/Clay Contact |
| Base composition | Tungsten |
| Nominal chemistry | W 45Ni 2.4C 1.8B |
| Max. service temp. | 500 |
| Achieved microhardness | 1500% |
| Achieved microhardness (min) | 50HRC |
| Achieved weld density | 12.2 |
| Recommended process technology |
Gas Metal Arc Welding |
| Datasheet number | DSM-0325 |
